Growatt SPH Series Installation Manual

Chart 4.1
Item Number Description
A 1 SPH inverter
B 1 User Manual
C 1 Paper board(installation guide)
D 1 Waterproof cover
E 1 AC Grid connector
F 1 EPS output connector
G 1 Communication cable
H 1 Current sensor
I 1 Lead-acid battery temperature sensor
J 1 RJ45 connector
K 4 M6 setscrew
M 2 Battery power terminal
N 6 screw
O/P 2/2 MC4 connector
Q 1
Hex screwdriver
5 Installation
5.1 Basic installation requirements
A. The installation location must be suitable for SPH’s weight for a long period time
B. The installation location must conforms with dimension of SPH
C. Do not install the unit on structures constructed of flammable or thermo labile materials
D. The ingress Protection rate is IP65 and the pollution degree is PD2. Please refer to the below:

Growatt SPH Series Specifications

General

Type	Hybrid Inverter
Max. Input Voltage	600V
Number of MPPTs	2
Protection Rating	IP65
Output Power Range	3kW - 10kW
Rated AC Output Power	3-10 kW
Communication Interfaces	RS485, USB, Wi-Fi
Output Voltage	230 V
Frequency	50/60 Hz
Operating Temperature	-25°C to 60°C
Cooling Method	Natural Convection
