Growatt SPH Series Installation Manual

Inverter topology Non-isolated
Certificate No SAAXXX
3.3 Size and weight
Chart 3.1
A(mm) B(mm) C(mm) weight(kg)
SPH TL BL-UP 450 565 188 27
3.4 The advantage of the unit of SPH
Features below:
 All in one design. Can improve self consumption, back up and also Pinch the valley
 Smart management, work mode can be set
 Safe battery used
 Easy installation
 Two mpp tracker input
4 Unpacking
Please check whether external damage to the goods before unpacking.
After unpacking, please check whether the unit damage or missing parts, if it is happen, please contact with
supplier.
Growatt SPH series and accessories as follows:

Growatt SPH Series Specifications

General

Type	Hybrid Inverter
Max. Input Voltage	600V
Number of MPPTs	2
Protection Rating	IP65
Output Power Range	3kW - 10kW
Rated AC Output Power	3-10 kW
Communication Interfaces	RS485, USB, Wi-Fi
Output Voltage	230 V
Frequency	50/60 Hz
Operating Temperature	-25°C to 60°C
Cooling Method	Natural Convection
