Growatt SPH Series Installation Manual

I Wireless communication
J RS232
K RS485
L Buzzer(Reserved)
M
Warning
N
Fault
6.4.2 LED and button instruction
Chart 6.3
Location Description
A Status
B ESC- button(cancel control)
C Down-button
D Enter-button
E UP-button
Notice：
LED showing status of SPH, it has two colors, one is green and another is red. Please turn to 3.1 and read the
detail of LED
6.4.3 LCD display column
Grovett can provide a variety of rules and regulations of the machine, the customer received the machine,
according to their country, through the LCD selection to set the corresponding rules and regulations.

Growatt SPH Series Specifications

General

Type	Hybrid Inverter
Max. Input Voltage	600V
Number of MPPTs	2
Protection Rating	IP65
Output Power Range	3kW - 10kW
Rated AC Output Power	3-10 kW
Communication Interfaces	RS485, USB, Wi-Fi
Output Voltage	230 V
Frequency	50/60 Hz
Operating Temperature	-25°C to 60°C
Cooling Method	Natural Convection
