Growatt SPI 3000 - Wiring of Water Level Sensor

9
Push the threaded sleeve in to the socket element. Screw the pressue screw thightly onto the threaded sleeve.
Close the connector
Insert the AC onnnection plug into the AC connection receptable on the inverter.
Lock the housing Unlock the housing
Wiring of Water Level Sensor
DC Switch
Connect S2 and COM
Water Tube
Connect 3 Phase Output
Connect S4 and COM
Water Level Sensor 2
Water Pump
Water Level Sensor 1
Water Tank
Solar Panel
