a. Setting P00.01=0. Manual operation mode settings.
b. Set water pump nameplate parameters: P02.01 motor rated power value; P02.02 motor rated power value;
P02.04 motor rated voltage value; P02.05 motor rated current value.
c. Water output test of pump
Click the run button to observe the running frequency and wateroutput.Under the normal strong light
condition,if the working frequency is low or the water volume is small,it indicates that the motor line may be
connected reversely,so it is necessary to set function code P00.13=1 or exchange the wiring of two motor
lines.
d. After finishing parameter setting of water pump, set P00.01=1. The operation code channel is altered as
original automatic mode instruction.
Notice: If the inverter fails,set P00.18 to restore the factory settings.
