: The availability of these measurements requires that the data
register 00302 VolumeFlow is available and that a differential
temperature measurement is established by one of the below
means:
MGE model H/I:
• Direct measurement, where an analog or temperature input
has been configured to Remote differential temperature
• PumpLiquidTemp (register 00322) measured by build in
Grundfos sensor and RemoteTemp2 (register 00337)
measured by analog or temperature input.
• RemoteTemp1 (register 00320) and RemoteTemp2
(register 00337) measured by analog or temperature input.
MAGNA3:
For the calculation an estimated flow value and measurement of
the liquid temperature by the build-in temperature sensor is used.
Connection of an external temperature sensor is needed for the
pump to calculate the needed differential temperature.
00337 RemoteTemp2
Temperature at external temperature
sensor 2.
0.01 K H + S - 3 + S
00338 UserSetpoint User-selected setpoint. 0.01 % ●●●
00339 Diffpressure Pressure between pump flanges. 0.001 bar H + S - 3
00340 OutletPressure Pressure at pump outlet. 0.001 bar H + S - -
00341 RemotePressure2
Pressure measured by external
sensor 2.
0.001 bar H + S - -
00342 LoadPercent
Motor current in percent of rated
motor current.
0.01 % H - 3
00343
00344
PumpUNIX_RTC_HI
PumpUNIX_RTC_LO
Pump time and date in UNIX format
(seconds since 01-01-1970 00:00:00).
1 s H - 3
00345 MaxFlowLimit Actual maximum flow limit. 0.1 m
3
/h H - 3
00346 RemoteDiffTemp Remote differential temperature. 0.01 K H + S - -
00347 InletDiffPressure Inlet differential pressure. 0.001 bar H + S - -
00348 OutletDiffPressure Outlet differential pressure. 0.001 bar H + S - -
00349 RemoteDiffPressure Remote differential pressure. 0.001 bar H + S - -
00350 StorageTankLevel Storage tank level. 0.01 m H + S - -
00351 AmbientTemp Ambient temperature. 0.01 K H + S - -
00352
00353
HeatEnergyCounter_HI
►
HeatEnergyCounter_LO
►
Total accumulated heat energy in
pump life time
1kWh H + S - 3
00354
00355
HeatPower_HI
►
HeatPower_LO
►
Actual heat power 1 W H + S - 3
00356 HeatDiffTemp
►
Differential temperature between
forward and return pipe used for heat
calculation.
0.01 K H + S - 3
Address Register name Description Scale 0.25 - 7.5 kW 11-22 kW + CUE
MAGNA/
UPE
Note
A data value of 0xFFFF indicates "not available".
Note
Estimated flow can be used for monitoring
purposes only, but it is not recommended for
controlling purposes.
