Grundfos CIU 501 Instructions

English (GB)
5
4. Specifications
4.1 CIM module general data
4.2 CIM 200 Modbus RTU
The table below provides an overview of the specifications for the
Grundfos CIM 200 and CIU 200. For further details, please refer
to the specific sections of this functional profile.
* Can only be set via software.
General data Description Comments
Ambient humidity 30 % to 95 % Relative, non-condensing.
Operating temperature -20 °C to +45 °C
Storage temperature -25 °C to +70 °C
Battery, lithium-ion
The battery will only be charged if the
battery temperature is within 0 °C to +45 °C.
CIM 250 only.
GENIbus visual diagnostics LED2
Will be in one of these states:
Off, constantly green, flashing red, constantly red.
See section 5.5 Status LEDs.
Power supply (CIU) 24-240 V Located in the CIU.
GENIbus connection type (CIU) RS-485, 3-wire + screen Conductors: A, B and Y.
CIU box enclosure class IP54
CIU box dimensions (H x W x D) 182 x 108 x 82 mm
Modbus RTU specifications Description Comments
Modbus connector Screw-type terminal
3 pins.
See section 5. Modbus RTU, CIM 200 setup.
Modbus connection type RS-485, 2-wire + common
Conductors: D0, D1 and Common.
See section 5. Modbus RTU, CIM 200 setup.
Maximum cable length 1200 m Equals 4000 ft.
Slave address 1-247
Set via rotary switches SW6 and SW7.
See section 5.3 Modbus address selection.
Line termination On or Off
Set via DIP switches SW1 and SW2.
See section 5.4 Termination resistor.
Recommended cable cross sectional
cobber area
0.20 - 0.25 mm
2
AWG24 or AWG23
Supported transmission speeds
1200*, 2400*, 4800*, 9600, 19200,
38400 bits/s
Set via DIP switches SW4 and SW5.
See section 5.1 Setting the Modbus transmission
speed.
Start bit 1 Fixed value.
Data bits 8 Fixed value.
Stop bits 1 or 2
Set via DIP switch SW3.
See section 5.2 Setting the parity.
Parity bit Even parity, odd parity* or no parity
Set via DIP switch SW3.
See section 5.2 Setting the parity.
Modbus visual diagnostics LED1
Off, flashing green, flashing red, constantly red.
See section 5.5 Status LEDs.
Maximum number of Modbus devices 32
Using repeaters, this number can be increased.
Legal address range is 1-247.
Maximum Modbus telegram size 256 bytes
Total length. Node address and CRC included.
See section 13. Modbus RTU telegram examples.
