E-pump models H and I
9.8 Alarm simulation register block
Alarm simulation can be used to simulate alarms and warnings on
the E-pump. This is typically used when testing alarm event
handling in BMS/SCADA system controllers. A simulated alarm
will not cause the E-pump to stop running, but it will indicate the
alarm condition on the bus.
●: Always available.
H: Only available on model H and later versions.
3: Only available on MAGNA3.
Measured parameters
(Selected from display or handheld)
Grundfos
built-in
sensor
Grundfos
LiqTec
sensor
Mapped to Modbus register
Parameter
Analog input
AI1, AI2, AI3
Temperature PT100
input T1, T2
Pump inlet pressure ● InletPressure (00315)
Pump inlet diff. press ● InletDiffPressure (00347)
Pump outlet pressure ● OutletPressure (00340)
Pump outlet diff press ● OutletDiffPressure (00348)
Pump diff. pressure ●●DiffPressure (00339)
Remote pressure 1 ● RemotePressure1 (00316)
Remote pressure 2 ● RemotePressure2 (00341)
Remote diff. pressure ● RemoteDiffpressure (00349)
Feed tank level ● FeedTankLevel (00317)
Storage tank level ● StorageTankLevel (00350)
Pump flow ● VolumeFlow (00302)
Remote flow ● RemoteFlow (00314)
Pumped liquid temp ●●●●PumpLiquidTemp (00322)
Temperature 1 ●● RemoteTemp1 (00320)
Temperature 2 ●● RemoteTemp2 (00337)
Remote diff. temp ● RemoteDiffTemp (00346)
Ambient temperature ●● AmbientTemp (00351)
Motor bearing temp. BE ● BearingTempDE (00323)
Motor bearing temp. NDE ● BearingTempNDE (00324)
Other parameter ● AuxSensorInput (00325)
Address Register name Description 0.25 - 7.5 kW 11-22 kW + CUE
MAGNA
/UPE
00701 Simulation.AlarmCode
Alarm code to simulate. See section 16. Grundfos
alarm and warning codes.
H
●
3
00702 Simulation.WarningCode
Warning code to simulate. See section 16. Grundfos
alarm and warning codes.
H
●
3
00708 Simulation.Activate
Used to activate alarm simulation with alarms/
warnings selected from registers 00701 and 00702.
0: Deactivate simulation
1: Activate simulation
H
●
3
00709 Simulation.Active
Status on alarm simulation.
0: Alarm simulation not active
1: Alarm simulation active
H
●
3
