Address Register name Description CIM 200 CIM 260 CIM 500
00033 BatteryState
State of CIM 260 module battery
0: Battery not present
1: Battery must be replaced
2: Battery charging
3: Battery needs charging, but temperature too high
4: Battery needs charging, but temperature too low
5: Battery low
6: Battery OK
255: Battery state not available
- ● -
00034 ProductSoftwareVersionHI Product software version (BCD digit 1-4 aa.bb) ● ● ●
00035 ProductSoftwareVersionLO Product software version (BCD digit 5-8 cc.dd) ● ● ●
00036 ProductSoftwareDayMonth Product software date (BCD ddmm) ● ● ●
00037 ProductSoftwareYear Product software date (BCD yyyy) ● ● ●
9.4 Cellular network Real Time Clock
Address Register name Description
CIM
200
CIM
260
CIM
500
00080 SetUNIXRealTimeClockHI
Set real time clock (32 bit UNIX format)
Triggered on value change
- ● -
00081 SetUNIXRealTimeClockLO - ● -
00082 SetRtcSecond Set real time clock - seconds - ● -
00083 SetRtcMinute Set real time clock - minutes - ● -
00084 SetRtcHour Set real time clock - hours - ● -
00085 SetRtcDay Set real time clock - day - ● -
00086 SetRtcMonth Set real time clock - month - ● -
00087 SetRtcYear Set real time clock - year - ● -
00088 Bit 0: SetRtc Triggers setting of real time clock - s/m/h/d/m/y format - ● -
00089 StatusUNIXRealTimeClockHI
Real time clock (32 bit UNIX format)
- ● -
00090 StatusUNIXRealTimeClockLO - ● -
00091 StatusRtcSecond Real time clock - seconds - ● -
00092 StatusRtcMinute Real time clock - minutes - ● -
00093 StatusRtcHour Real time clock - hours - ● -
00094 StatusRtcDay Real time clock - day of month - ● -
00095 StatusRtcMonth Real time clock - month - ● -
00096 StatusRtcYear Real time clock - year (after 2000) - ● -
00097 Bit 0: StatusSetRTCAck Acknowledge of set RTC command - ● -
19
