Grundfos CIU 501 User Manual

E-pump models H and later
Measured parameters
(selected from display or handheld)
Grundfos built-in
sensor
Grundfos LiqTec
sensor
Mapped to Modbus register
Parameter
Analog input AI1, AI2,
AI3
Temperature Pt100 input
T1, T2
Pump inlet pressure ● InletPressure (00315)
Pump inlet diff. press ure ● InletDiffPressure (00347)
Pump outlet pressure ● OutletPressure (00340)
Pump outlet diff. press ure ● OutletDiffPressure (00348)
Pump diff. pressure ● ● DiffPressure (00339)
Remote pressure 1 ● RemotePressure1 (00316)
Remote pressure 2 ● RemotePressure2 (00341)
Remote diff. pressure ● RemoteDiffpressure (00349)
Feed tank level ● FeedTankLevel (00317)
Storage tank level ● StorageTankLevel (00350)
Pump flow ● VolumeFlow (00302)
Remote flow ● RemoteFlow (00314)
Pumped liquid temp ● ● ● ● PumpLiquidTemp (00322)
Temperature 1 ● ● RemoteTemp1 (00320)
Temperature 2 ● ● RemoteTemp2 (00337)
Remote diff. temp ● RemoteDiffTemp (00346)
Ambient temperature ● ● AmbientTemp (00351)
Motor bearing temp. BE ● BearingTempDE (00323)
Motor bearing temp. NDE ● BearingTempNDE (00324)
Other parameter ● AuxSensorInput (00325)
9.9 Alarm simulation register block (not CUE)
Alarm simulation can be used to simulate alarms and warnings on the E-pump. This is typically used when testing alarm event handling in
BMS/SCADA system controllers. Whether the Simulation. AlarmCode register or the Simulation. WarningCode register is used makes no
difference. The pump will in both cases react according to the predefined reaction to the code in question.
For the complete list, see chapter Alarms and warnings.
Not all codes apply to all E-pump types.
Address
Register name Description 0.25 - 7.5 kW 11-22 kW MAGNA3
00701 Simulation. AlarmCode Alarm code to simulate. H ● ●
00702 Simulation. WarningCode Warning code to simulate. H ● ●
00708 Simulation. Activate
Used to activate alarm simulation with alarms and warnings
selected from registers 00701 and 00702.
0: Deactivate simulation
1: Activate simulation
H ● ●
00709 Simulation. Active
Status on alarm simulation.
0: Alarm simulation not active
1: Alarm simulation active
H ● ●
●: Always available.
H: Only available on model H and later versions.
Related information
10.4 Alarms and warnings
9.10
User register block
Address Register name R/W Scale Description
00751-00800 UserRegisters R/W Unscaled
This area is for device labelling by the user.
The user area values are stored in the device and will remain
after a power-off.
28
English (GB)
