Address Register name Description
00105
RelayControl A register to control the relays. It is bitwise interpreted as follows:
Bit 0: Relay1Control
Controls the state of relay 1.
0: Closed
1: Open
Only E-pumps and CUE.
Bit 1: Relay2Control
Controls the state of relay 2.
0: Closed
1: Open
Only CUE, large MGE, MGE model H and later.
Bits 2: Relay3Control
Controls the state of relay 3.
0: Closed
1: Open
Only MGE model H and later.
Bits 3: Relay4Control
Controls the state of relay 4.
0: Closed
1: Open
Only MGE model H and later.
Bits 4-15: RESERVED -
00106 SetMaxFlowLimit
Sets the maximum flow limit, FLOWLIMIT. It must be enabled in register 00101, bit 5.
The value is set in 0.01 m
3
/h. If enabled, the FLOWLIMIT is active in all control modes. If disabled, the
maximum flow limit will only be active in FLOWADAPT control mode.
Read actual value in register 00345
Only available on MAGNA3 and MGE model H and later.
00107 SetPumpUnixRtcHI
Sets the real-time clock in the pump in unix format (seconds since 01-01-1970).
Only available on MAGNA3 and MGE model H and later.
00108 SetPumpUnixRtcLO
00109 SensorFeedback Closed loop sensor feedback via Modbus, scaling 0.01 %
00110 SetKp
Sets the proportional gain, Kp. The scale is 0.1.
Only available on MAGNA3 and MGE model H and later.
00111 SetTi
Sets the integral action time, Ti. The scale is 0.1 s.
Only available on MAGNA3 and MGE model H and later.
00112 SetDirectCtr
Selection of Direct/Inverse control.
0: Inverse control
1: Direct control
Only available on MAGNA3 and MGE model H and later.
Related information
9.2 CIM configuration register block
10.1 Control mode
10.2 Setpoint in closed-loop control
21
