Address Register name Description Scale 0.25 - 7.5 kW 11-22 kW + CUE MAGNA3
00334
00335
NumberOfStartsHI
NumberOfStartsLO
Number of times the E-pump has been
started.
1 start ● ● ●
00336 RESERVED -
00337 RemoteTemp2
Temperature at external temperature
sensor 2.
0.01 K H + S - S
00338 UserSetpoint
User-selected setpoint.
Open loop: % of nominal frequency.
Closed loop: % of setpoint range.
0.01 % ● ● ●
00339 Diffpressure Pressure between pump flanges. 0.001 bar H + S - ●
00340 OutletPressure Pressure at pump outlet. 0.001 bar H + S - -
00341 RemotePressure2 Pressure measured by external sensor 2. 0.001 bar H + S - -
00342 LoadPercent
Motor current in percent of rated motor
current.
0.01 % H - -
00343
00344
PumpUnixRtcHI
PumpUnixRtcLO
Pump time and date in UNIX format
(seconds since 01-01-1970 00:00:00).
1 second H - ●
00345 MaxFlowLimit Actual maximum flow limit.
0.1 m
3
/h
H - ●
00346 RemoteDiffTemp Remote differential temperature .. 0.01 K H + S - -
00347 InletDiffPressure Inlet differential pressure. 0.001 bar H + S - -
00348 OutletDiffPressure Outlet differential pressure. 0.001 bar H + S - -
00349 RemoteDiffPressure Remote differential pressure. 0.001 bar H + S - -
00350 StorageTankLevel Storage tank level. Offset -100. 0.01 m H + S - -
00351 AmbientTemp Ambient temperature. 0.01 K H + S - -
00352
00353
HeatEnergyCounter1HI
►
HeatEnergyCounter1LO
►
Total accumulated heat energy in pump
lifetime (direction 1).
1 kWh H + S - S
00354
00355
HeatPowerHI
►
HeatPowerLO
►
Actual heat power. 1 W H + S - S
00356
HeatDiffTemp
►
Differential temperature between forward
and return pipe used for heat calculation.
0.01 K H + S - S
00357
00358
Volume1HI
Volume1LO
Total pumped volume (direction 1).
0.01 m
3
H + S CUE + S ●
00359
HeatEnergyCounter2HI
►
Total accumulated heat energy in pump
lifetime (direction 2).
1 kWh H + S - S
00360
HeatEnergyCounter2LO
►
00361 Volume2HI
Total pumped volume (direction 2).
0.01 m
3
H + S - ●
00362 Volume2LO
►
: The availability of these measurements requires that the data register 00302 VolumeFlow is available and that a differential temperature
measurement is established by one of the below means:
MGE model H and later:
• Direct measurement, where an analog or temperature input has been configured to Remote differential temperature RemoteDiffTemp
(register 00346).
• PumpLiquidTemp (register 00322) measured by build-in Grundfos sensor and RemoteTemp2 (register 00337) measured by analog or
temperature input.
• RemoteTemp1 (register 00320) and RemoteTemp2 (register 00337) measured by analog or temperature input.
MAGNA3:
For the calculation, an estimated flow value and measurement of the liquid temperature by the build-in temperature sensor is used.
Connection of an external temperature sensor is needed for the pump to calculate the needed differential temperature.
A data value of 0xFFFF indicates "not available".
Estimated flow can be used for monitoring purposes only. We do not recommend it for controlling purposes.
26
