Terminal Type Function
NC Normally closed contact
Signal relay 1. LIVE or PELV.C1 Common
NO Normally open contact
NC Normally closed contact
Signal relay 2. PELV only.C2 Common
NO Normally open contact
10 DI3/OC1
Digital input/output, configurable.
Open collector: Maximum 24 V resistive or inductive.
4
With standard product delivery,
analog inputs 1 and 2 are used
by the sensor.
AI1
Analog input:
0-20 mA or 4-20 mA
0.5-3.5 V, 0-5 V or 0-10 V.
2 DI1
Digital input, configurable.
Digital input 1 is factory-set to be start or stop input where an open circuit
results in stop. A jumper has been factory-fitted between terminals 2 and
6. Remove the jumper if digital input 1 is to be used as external start or
stop or any other external function.
5 +5 V Power supply to a potentiometer or sensor.
6 GND Ground.
A GENIbus, A GENIbus, A (+).
Y GENIbus, Y GENIbus, Y (GND).
B GENIbus, B GENIbus, B (-).
3 GND Ground.
15 +24 V Power supply.
8 +24 V Power supply.
26 +5 V Power supply to potentiometer and sensor.
23 GND Ground.
25 GDS TX Grundfos Digital Sensor output.
24 GDS RX Grundfos Digital Sensor input.
7
With standard product delivery,
analog inputs 1 and 2 are used
by the sensor.
AI2
Analog input:
0-20 mA or 4-20 mA.
0.5 - 3.5 V, 0-5 V or 0-10 V.
6.3.2 Signal relays
The motor has two outputs for potential-free signals via two internal
relays. You can set the signal outputs to Operation, Pump
running, Ready, Alarm and Warning.
The functions of the two signal relays appear from the table below:
Grundfos Eye is off
The power is off.
Operation Pump running Ready Alarm Warning Operating mode
-
Grundfos Eye is rotating green
The pump or motor runs in Normal mode in open or closed loop.
