Product range
Overview
The CUE cabinet sizes are characterised by their
enclosures. The table shows the relation between
power size (P2), mains supply (V) and enclosure class
(IP). It shows the complete range of the CUE.
* CUE Hp ratings do not always match motor Hp ratings. Always size CUE by max amperage output and motor amperage.
Typical shaft power P2
Mains supply and enclosure class
1 x 200-240 V 3 x 200-240 V 3 x 380-500 V 3 x 525-600 V 3 x 525-690 V
[kW] [HP]* IP20 IP21 IP55 IP20 IP55 IP20 IP21 IP54 IP55 IP20 IP55 IP21 IP54 IP55
0.55 0.75
z z
0.75 1
z z z z z z
1.1 1.5
z z z z z z z z
1.5 2
z z z z z z z z
2.2 3
z z z z z z z z
34
z z z z z z z z
3.7 5
z z z z
45
z z z z
5.5 7.5
z z z z z z z z
7.5 10
z z z z z z z z
11 15
z z z z z z
15 20
z z z z z z
18.5 25
z z z z z z
22 30
z z z z z z
30 40
z z z z z z
37 50
z z z z z z
45 60
z z z z z z
55 75
z z z z
75 100
z z z z
90 125
z z z z
110 150
z z z z
132 200
z z z z
160 250
z z z z
200 300
z z z z
250 350
z z z z

Grundfos CUE Series Specifications

General

Category	DC Drives
Output Voltage	24 V DC
Control Signal	0-10 V, 4-20 mA
Communication	Modbus RTU
Protection Features	Overvoltage, overcurrent, overtemperature, short circuit
Humidity	5% to 95% (non-condensing)
Enclosure class	IP20
Enclosure Rating	IP20
