Grundfos CUE Series - Technical Data; Main Dimensions and Weight

Grundfos CUE
45
Technical data
Main dimensions and weight
TM03 9000 2807
TM03 9002 2807
Fig. 50 Enclosures A2 and A3 Fig. 51 Enclosures A5, B1, B2, B3, B4, C1, C2, C3 and C4
B4, C3, C4
TM03 9922 4607
Fig. 52 Enclosures D1 and D2
Enclosure
Height [in (mm)]
1)
Width [in (mm)]
1)
Depth [in (mm)]
1)
Screw holes [in (mm)]
Weight
[lb (kg)]
AaBbC
C
2)
c ∅d ∅ef
A2 10.55
(268)
10.12
(257)
3.54
(90)
2.76
(70)
8.08
(205)
8.62
(219)
.315
(8.0)
.433
(11)
.217
(5.5)
.354
(9.0)
10.8
(4.9)
with IP21/NEMA1 kit 14.76
(375)
13.78
(350)
3.54
(90)
2.76
(70)
8.08
(205)
8.62
(219)
.315
(8.0)
.433
(11)
.217
(5.5)
.354
(9.0)
11.7
(5.3)
A3 10.55
(268)
10.12
(257)
5.12
(130)
4.34
(110)
8.08
(205)
8.62
(219)
.315
(8.0)
.433
(11)
.217
(5.5)
.354
(9.0)
14.6
(6.6)
with IP21/NEMA1 kit 14.76
(375)
13.78
(350)
5.12
(130)
4.34
(110)
8.08
(205)
8.62
(219)
.315
(8.0)
.433
(11)
.217
(5.5)
.354
(9.0)
15.4
(7.0)
A5 16.54
(420)
15.83
402)
9.53
(242)
8.47
(215)
7.87
(2
00)
7.87
(200)
.323
(8.2)
.472
(12)
.256
(6.5)
.354
(9.0)
30.9
(14)
B1 18.90
(480)
17.87
(454)
9.53
(242)
8.27
(210)
10.24
(260)
10.24
(260)
.472
(12.0)
.748
(19)
.354
(9.0)
.354
(9.0)
26.5
(23)
B2 25.59
(650)
24.57
(624)
9.53
(242)
8.27
(210)
10.24
(260)
10.24
(260)
.472
(12.0)
.748
(19)
.354
(9.0)
.354
(9.0)
59.5
(27)
B3 15.71
(399)
14.96
(380)
6.50
(165)
5.52
(140)
9.76
(248)
10.32
(262)
.315
(8.0)
.472
(12)
.268
(6.8)
.311
(7.9)
26.5
(12)
with IP21/NEMA1 kit 18.71
(475) –
6.50
(165) –
9.80
(249)
10.32
(262)
.315
(8.0)
.472
(12)
.268
(6.8)
.311
(7.9) –
B4 20.47
(520)
19.49
(495)
9.09 in
(231)
7.
87
(200)
9.53
(242)
9.53
(242) – –
.335
(8.5)
.591
(15.0)
51.8
(23.5)
with IP21/NEMA1 kit 26.38
(670) –
10.04
(255) –
9.69
(246)
9.69
(246) – –
.335
(8.5)
.591
(15.0) –
C1 26.77
(680)
25.52
(648)
12.13 in
(308)
10.71
(272)
12.21
(310)
12.21
(310)
.472
(12.0)
.748
(19)
.354
(9.0)
.386
(9.8)
99.2
(45)
