8.8.8 PROFIBUS-DP (option)
PROFIBUS DP communication is realised via a gateway to transfer
data from “MODBUS TCP Client” to “PROFIBUS Slave”. This
enables customers to change all PROFIBUS parameters.
Each device in a PROFIBUS DP network is associated with a
Generic Station Description file (GSD file), which describes the
implementation of the product. The GSD file is used by the network
configuration tool to configure the network.
The current version of the GSD file for the "Anybus" gateway can be
downloaded from the HMS website on:
http://www.anybus.com
Use the file „HMSA1837“.
To enable PROFIBUS DP communication, the MODBUS TCP must
be selected.
Parameter settings
Remote IP address: 0.0.0.0 = any client
Remote Port: 0 = any
Local Port: 502
Interface data
Features:
• Automatic baud rate detection up to 12 Mbit/s
• No proprietary configuration software is needed. All necessary
configuration is made via the built-in web interface.
Recommended adjustments for PROFIBUS:
Word input
Word output
Control / Status
Word:
1 1
Live list 4
Input address: 16
Output address: 16
PROFIBUS address
(can be changed via
webserver in
device):
16
Related information
8.8.9 Output addresses (Polydos to SCADA)
8.8.10 Input addresses (SCADA to Polydos)
8.8.9 Output addresses (Polydos to SCADA)
Data block DB100: Register 0 … 9 (40001 - 40010) = DB100.DBW0
… DBW18
DBW0 - Register 0 / 40001 output word 1
• Format: BOOL
• Type of signal: permanent
Address Description State
DB100.DBX0.0 Stirrer 1 in operation TRUE
DB100.DBX0.1 Stirrer 2 in operation TRUE
DB100.DBX0.2 Stirrer 3 in operation TRUE
DB100.DBX0.3 Dry-material feeder in operation TRUE
DB100.DBX0.4
Liquid-concentrate pump in
operation
TRUE
DB100.DBX0.5 Solenoid valve is open TRUE
DB100.DBX0.6 Vibrator in operation TRUE
DB100.DBX0.7 RESERVE TRUE
DB100.DBX1.0
FALSE: Dry-material dosing mode
active
TRUE: Liquid-concentrate dosing
mode active
FALSE
/ TRUE
DB100.DBX1.1
FALSE: Control mode "Local" active
TRUE: Control mode "Remote"
active
FALSE
/ TRUE
DB100.DBX1.2 Operation mode "Automatic" active TRUE
DB100.DBX1.3
FALSE: External contact is open
TRUE: External contact is closed
FALSE
/ TRUE
DB100.DBX1.4 RESERVE TRUE
DB100.DBX1.5 RESERVE TRUE
DB100.DBX1.6 RESERVE TRUE
DB100.DBX1.7 RESERVE TRUE
DBW2 - Register 1 / 40002 output word 2
• Format: BOOL
• Type of signal: permanent
Address
Description State
DB100.DBX2.0 Fault motor stirrer 1 TRUE
DB100.DBX2.1 Fault motor stirrer 2 TRUE
DB100.DBX2.2 Fault motor stirrer 3 TRUE
DB100.DBX2.3 Fault motor dry-material feeder TRUE
DB100.DBX2.4 Fault motor liquid-concentrate pump TRUE
DB100.DBX2.5 RESERVE TRUE
DB100.DBX2.6 RESERVE TRUE
DB100.DBX2.7 Fault vibrator TRUE
DB100.DBX3.0 Water flow too low (FSAL) TRUE
DB100.DBX3.1 Water flow too high (FSAH) TRUE
DB100.DBX3.2 Lack of dry material (LSL) TRUE
DB100.DBX3.3 Dry-material feeder empty (LSAL) TRUE
DB100.DBX3.4
Flow of liquid concentrate very low
(FSAL)
TRUE
DB100.DBX3.5 Wrong input of parameter TRUE
DB100.DBX3.6 Collecting fault TRUE
DB100.DBX3.7 Fault vacuum loader TRUE
40
