Grundfos Polydos 412E User Manual

8.7 Menu structure
The following table shows the structure of menus which can be accessed via the main menu System overview (8.7.1 System overview).
Symbol Submenu 1 Symbol Submenu 2 Symbol Submenu 3
Dry-material feeder (8.7.2 Dry-material feeder parameters)
Start-up dry-material feeder (8.7.3 Dry-material feeder calibration)
Liquid-concentrate pump (8.7.4 Liquid-concentrate pump parameters)
Start-up liquid-concentrate pump (8.7.5 Liquid-concentrate pump calibration)
Water unit (8.7.6 Water unit)
Set-up - Flow sensor (8.7.7 Set-up - Flow sensor)
Tank (8.7.8 Tank)
Set-up - Level sensor (8.7.9 Set-up - Level sensor)
Trend 1h (8.7.10 Trend 1h / Trend 24h)
Trend 24h
System menu (8.7.11 System menu)
Tag number editor (8.7.12 Tag number editor)
Operating hours counter (8.7.13 Operating hours counter)
Language selection (8.7.14 Language selection)
Time / Date (8.7.15 Time / Date)
User administration (8.7.16 User administration)
Message administration (8.7.17 Message administration)
Status PLC inputs / outputs (8.7.18 Status of PLC inputs/outputs)
Service menu (8.8 Service menu)
Start-up dry-material feeder (7.1 Commissioning for operation with
dry material)
Start-up liquid-concentrate pump (7.2 Commissioning for operation
with liquid concentrate)
Data backup (8.8.1 Data backup)
MODBUS-TCP - Parameters (8.8.4 MODBUS-TCP - Parameters)
MODBUS-RTU - Parameters (8.8.5 MODBUS-RTU - Parameters)
Interface data (8.8.7 Interface data)
21
English (GB)
