Grundfos SCALA1 User Manual

Pos.
H1
[mm]
[inch]
H2
[mm]
[inch]
H3
[mm]
[inch]
L1
[mm]
[inch]
B1
[mm]
[inch]
SCALA1 (all variants)
316
12.4
263
10.4
171
6.7
466
18.4
202
8.0
Weight
SCALA1 3-25
[kg]
[lb]
SCALA1 3-35
[kg]
[lb]
SCALA1 3-45
[kg]
[lb]
SCALA1 5-25
[kg]
[lb]
SCALA1 5-25
[kg]
[lb]
11
24.2
12
26.4
12
26.4
12
26.4
14
30.8
36
English (GB)

Grundfos SCALA1 Specifications

General

Inlet/Outlet Size	1 inch
Weight	10 kg
Mains Frequency	50/60 Hz
Pumped liquid	Clean water
Housing Material	Composite
Pump Type	Self-priming, multistage centrifugal pump
Power Supply	1 x 230 V
Liquid Temperature Range	0°C to 45°C
Protection Class	IPX4D
System Pressure	Max. 10 bar
Approvals	CE, EAC
Installation Type	Horizontal
