2.4.2 Type key for SCALA1
Example:
SCALA1 . 5- . 25 . 1x230V . 50 Hz . SCHUKO
Description
SCALA1 Type range
3
5
Max. flow rate [m
3
/h]
25
35
45
55
Max. head [m]
1x230V
1x115V
Voltage [V]
50 Hz
60 Hz
Frequency [Hz]
SCHUKO (Type E/F)
No plug
Thailand (Type O)
Australia (Type I)
UK (Type G)
US (Type NEMA 5-15, NEMA
6-15)
Argentina (Type I)
Plug type
3. Receiving the product
3.1
Inspecting the product
On receipt of the product, do the following:
1. Check that the product is as ordered.
If the product is not as ordered, contact the
supplier.
2. Make sure that the supply voltage and frequency
correspond to the values stated on the product
nameplate.
3.2
Scope of delivery
The box contains the following items:
• 1 Grundfos SCALA1 pump
• 1 quick guide
• 1 safety instructions booklet.
4. Installation requirements
4.1
Location
The product can be installed both indoors and
outdoors.
Please observe the following:
• Install the product to enable easy inspection,
maintenance, and service.
• We recommend that you place the product as
close as possible to the liquid to be pumped.
• We recommend that you install the product near
a drain or in a drip tray connected to a drain in
order to lead away possible condensation from
cold surfaces.
4.1.1 Installation of the product in a frosty
environment
Protect the product from freezing if it is to be installed
outdoors where frost may occur.
4.1.2 Minimum space
The pump requires a minimum space of 495 x 225 x
340 mm (19.5 x 8.9 x 13.4 inches).
Even though the pump does not require much space,
we recommend that you leave enough space for
service and maintenance access.
4.2 Maximum system pressure
Make sure that the system in which the
pump is installed is designed for the
maximum pump pressure
The maximum inlet pressure depends on the head at
the actual duty point. The sum of the inlet pressure
and the head must not exceed the maximum system
pressure.
We recommend installing a pressure-relief valve to
protect the pump so that the outlet pressure does not
exceed the maximum system pressure.
5. Mechanical installation
WARNING
Electric shock
Death or serious personal injury
‐ Switch off the power supply before you
start any work on the product. Make
sure that the power supply cannot be
switched on accidentally.
WARNING
Electric shock
Death or serious personal injury
‐ Mount the product horizontally to avoid
condensation in the electrical insulation
inside the control box.
WARNING
Chemical hazard
Death or serious personal injury
‐ Before the pump is used for supplying
drinking water, flush the pump
thoroughly with clean water.
7
English (GB)
