Grundfos TP Service Instructions

English (GB)
6
4. Torques and lubricants
Pos. Designation
Quantity
TP/TPD
Dimensions Torque [Nm] Lubricant
7a Screw 4/8 M6 6 Loctite 243
9 Screw 2/4
M5 5
Loctite 243M6 8
M8 15
17 Vent screw 1/2 1/8" 8 Loctite 243
18 Pipe plug 2/2 1/4" 20 Loctite 243
19 Pipe plug 1/4 1/8" 10 Loctite 243
20 Pipe plug 2/4 3/8" 25 Loctite 243
26 Staybolt 6, 8, 10/12, 16, 20 M10 45
36 Nut for pump housing 6, 8, 10/12, 16, 20 M10 45
36a Nut for motor 4/8
M6 5
M8 12
M12 40
M16 100
51 Shaft 1/2 Rocol 22
67 Impeller nut 1/2 M14 40
72a O-ring/gasket 1/2 Rocol 22
105 Shaft seal 1/2 Soapy water
211 Screw 0/6 M6 6
222 Pipe plug 0/1 1/8" 10 Loctite 243
Product Product number
Loctite 243 V7137215
Rocol 22 00RM2924

Grundfos TP Specifications

General

Motor Efficiency	IE3
Series	TP
Connection Type	Flanged
Protection Class	IP55
Installation	In-line
Material	Stainless Steel
Maximum Operating Pressure	16 bar
Flange Standard	EN 1092
Pump Housing Material	Stainless Steel
Impeller Material	Stainless Steel
Temperature Range	-25 °C to +120 °C
Liquid Temperature Range	-25 °C to +120 °C
