Grundfos TP Service Instructions

English (GB)
8
5.2 Standard tools
5.3 Torque tools
Pos. Designation For pos.
Further information
[mm]
Product number
D Strap wrench 49 00SV0853
E Puller 49
F Pinch bar 51 SV5201
G Ring/open-end spanner 36, 36a, 67
17
19
22
24
30
36
SV0056
SV0063
00SV0186
SV0122
SV0073
H Multigrip pliers 11 SV0150
I Plastic hammer 2, 77 SV0349
J Screwdriver 105
K Cross-recess screwdriver 7a
L Hexagon key 9, 9a
2.5
3
4
6
10
SV0277
SV0278
SV0196
SV0033
M Hexagon socket 36, 36a, 67
13
17
19
22
24
27
30
36
41
50
SV0413
SV0417
SV0419
SV0422
SV0424
SV0427
N Bits kit 7a, 9, 9a SV2010
O Ratchet handle N 96777072
Pos. Designation For pos. Further information Product number
P Torque screwdriver N 1-6 Nm SV0438
Q Torque wrench Q
9 x 12 mm - 4-20 Nm
9 x 12 mm - 20-100 Nm
14 x 18 mm - 40-200 Nm
SV2092
SV0269
SV0400
R Ratchet insert tool M
9 x 12 mm - 1/2"
14 x 18 mm
SV0295
SV0401

Grundfos TP Specifications

General

Motor Efficiency	IE3
Series	TP
Connection Type	Flanged
Protection Class	IP55
Installation	In-line
Material	Stainless Steel
Maximum Operating Pressure	16 bar
Flange Standard	EN 1092
Pump Housing Material	Stainless Steel
Impeller Material	Stainless Steel
Temperature Range	-25 °C to +120 °C
Liquid Temperature Range	-25 °C to +120 °C
