Grundfos UPM3S Series User Manual

Cast-iron electrocoated (CED) in-line
housings with threads
TM064423
CED 15 x 130 mm
TM064424
CED 25 x 130 mm
TM064425
CED 25 x 180 mm
TM064426
CED 32 x 180 mm
Stainless-steel (N) in-line housings with
threads - approved for drinking water
TM068465
NIRO 15 x 130 mm
TM064427
NIRO 25 x 130 mm
TM064428
NIRO 25 x 180 mm
TM064429
NIRO 32 x 180 mm
Cast-iron electrocoated (CED) OEM
housings - end-suction with threads or in-
line with air outlet
A
B
TM064430
GGES cast-iron, end-
suction
B
AC
TM068467
GGES cast-iron, end-
suction
Pos. Description
A Outlet 1" thread connection
B Inlet 1" thread connection
C Air outlet 3/8" for external air vent
Cast-iron electrocoated (CED) OEM
housings - end-suction for back-panel
mounting
A
B
TM064431
GGMBP3 cast-iron, mini
back-panel
C
D
TM064432
GGBP3 cast-iron, maxi
back-panel
Pos. Description
A Inlet Ø26 mm
B Outlet Ø19 mm
C Outlet Ø24.5 mm
D Inlet Ø24.5 mm
Composite in-line housings with threads,
integrated vent and additional connections
A
B
TM064433
CIL3 composite, inline, 1"
x 130 mm
A
C
D
D
B
TM064434
CACAO composite,
alternate connection, air
outlet
UPM3
9
39
