Introduction
The Digta W/LAN-Adapter is used in combination with a Digta dictating machine and
a Digta Station for the transfer of dictations directly over the LAN (wireless LAN
optional). This means that a Digta Station with the Digta W/LAN-Adapter can also
be used in places where no PC is available.
Preparation
In order to set up the Digta W/LAN-Adapter a PC with Microsoft Windows
®
operating
system (Windows XP and above) is required, together with an Ethernet network with
RJ45 connection. Connect the RJ45 connector of the Ethernet cable to the
“ETHERNET” socket and your network, and the connector of the power supply to
the ”–o– ” socket.
Display, LEDs
ETHERNET: jittering = data transfer
INTERNET: without function
WLAN: on = wireless LAN connection
off = LAN connection
Basic configuration
For configuration purposes it is necessary to assign an IP address to the
Digta W/LAN-Adapter and incorporate it into the existing network.
To do this, run the configuration tool “DigtaLANConfig.exe” on your PC.
d
TIP
The Digta W/LAN-Adapter may also be connected directly to the network
card of a PC for configuration. In this case a "crossed" cable is required
(not included in the scope of supply).
d
TIP
Configuration is only possible via an Ethernet cable connection!
Even if an optional WLAN connection is present, it is not suitable for
configuration!
