GST200-2 Intelligent Fire Alarm Control Panel
Installation and Operation Manual
Page 41
Pressing TEST can enter test mode setup screen as shown in Fig. 6-31.
Fig. 6-31
In this screen, the user can carry out self-test on audible/visual performance, setting up
single-zone testing, exiting single-zone testing mode and exiting testing of all zones.
6.3.7.1 Audible/Visual Self-test
Entering 1 in the screen of Fig. 6-31, if the system is in normal standby state, the FACP
will self-test all indicators and audible components.
6.3.7.2 Single-zone Testing Setup
Entering 2 in the screen of Fig. 6-30 will enter the screen for setting up single-zone
testing, as shown in Fig. 6-32.
Fig. 6-32
Entering the zone to test in this screen and pressing ENTER to confirm, the zone will
enter test mode, and the TEST MODE indicator will illuminate.
6.3.7.3 Exiting Single-zone Testing Mode
Entering 3 in the screen of Fig. 6-31 will enter the screen for exiting single-zone test
mode, as shown in Fig. 6-33.
Fig. 6-33
Entering the number of the zone to exit test mode and pressing ENTER to confirm will
enable the zone to exit test mode.
*Test Mode*
1 Display Test
2 Each Zone In Test
3 Stop a Zone Test
4 Stop All Zone Test
Stop a Zone In Test
Zone: 000
Start a Zone In Test
Zone: 000
