GST200-2 Intelligent Fire Alarm Control Panel
Installation and Operation Manual
Page 5
 Nexans NX 200 and 200 Plus (LPCB tested)
 Prysmian FP 200 and 200 Gold
 Draka Firetuf and Firetuf Plus
And all LPCB approved Fire cables
 Recommended Cable Length ≤1000m
2.3.2 RS232 Communication Loop
RS232 communication loop is connected with a PC for running GstGMC2.0 Graphic
Monitor Center (GMC) system PC through a DB9 port.
Recommended Wiring: Standard RS-232 interface. The 2
nd
pin (for sending data), the
3
rd
pin (for receiving data), and the 5
th
pin (ground) are connected with PC through
three-core shield cable.
Note: Wire length should be less than 15m; the screening layer and computer’s
enclosure should be earthed.
2.4 Detection Loop Parameters
 LOOP OUT (+, -): Polarized signal cable from the FACP connecting up to 235
addressable devices.
 LOOP IN (+, -): Polarized signal cable returning to the FACP.
 LOOP2 ZO (+, -): Polarized signal cable from the 2
nd
loop of the FACP connecting
up to 242 addressable devices.
 LOOP2 ZI (+, -): Polarized signal cable from the 2
nd
loop returning to the FACP.
 Output Voltage: 21V～27V pulse
 Output Current: 0mA～300mA
 Type of Loop: Class A loop
 Recommended Wiring (subject to local installation codes):
 GST fire cable
 Vencroft Gold and Platignum
 Nexans NX 200 and 200 Plus (LPCB tested)
 Prysmian FP 200 and 200 Gold
 Draka Firetuf and Firetuf Plus
And all LPCB approved Fire cables.
 Recommended Cable Length ≤1000m
2.5 Output Loop Parameters
 Recommended Wiring (subject to local installation codes):
 GST fire cable
 Vencroft Gold and Platignum
 Nexans NX 200 and 200 Plus (LPCB tested)
 Prysmian FP 200 and 200 Gold
 Draka Firetuf and Firetuf Plus
And all LPCB approved Fire cables
 Recommended cable length ≤1000m
2.5.1 FIRE ALARM OUTPUT (+, -)
