5 Sings and Labels
The following markings shall be affixed to the CoboSafe CBSF:
CAUTION
Danger of Crushing
The sign indicates a danger of crushing hands and fingers. Ne-
ver touch the force sensor during measurement.
Type plate
The type plate is attached to the side of the CoboSafe-CBSF force sensor. The type plate
contains the following data:
■ Device type
■ Spring constant (Spring Rate)
■ Maximum Force
■ Temperature range (Temp)
■ Year of manufacturing (Year of M)
■ Article number (Art.-Nr.)
■ Serial number (Serial)
■ Charging voltage
(input)
■ CE label
The numerical appendix for the type designation corresponds to the indi-
cation of the spring constant.
Example: CBSF-150 = Force sensor with 150 N/mm spring constant.
Abb. 4: Type plate
Fig. 3: danger of crushing
