STRUCTURE AND FUNCTION COBOSAFE-CBSF
7 Structure and Function CoboSafe-CBSF
7.1 CoboSafe-CBSF-Force Sensors
■ Measuring body [1]
■ Measuring plate [2]
■ Display [3]
■ Pushbutton on rear panel [4]
■ Base plate [5]
■ Handle surfaces [6]
■ Holder and mounting option for adapter. Threaded hole M4 x 8 mm. [7]
Dimensioned drawing of the base plate
A dimensioned drawing of the base plate can be found in the appendix.
7
6
6
5
1
4
2
3
Fig. 7: CoboSafe-CBSF
