Gtec LibraPro - Electrical data for inverter and bypass

0MNMPMK10NPENUB 00 Pag. 55 / 57
Electrical Data 10 15 20 30 40 60 80 100
INVERTER
Rated power Pf 0.9 inductive [kVA] 10 15 20 30 40 60 80 100
Active power Pf 1 [kW] 9
13,5
18 27 36 54 72 90
Rated voltage 230Vca 1-phase+N (configurable from 220V to
240V)
Rated voltage adjustment field from 208 to 242V
Rated frequency [Hz] 50 or 60 (configurable)
Static variation ± 1%
Dynamic variation ± 5%
Recovery time within ± 1% 20ms
Conforms to standard EN 62040-3, class 1
Current peak factor (Ipeak/Irms as per EN 62040-3) 3:1
Voltage distortion with linear load 1% (typical), 2% (max)
Voltage distortion with non linear load (EN 62040-3) < 3%
Stability of frequency with Inverter synchronized with the by-
pass mains
± 2% (adjustable from ± 1% to ± 6% from control
panel)
Stability of frequency with Inverter not synchronized with the
by-pass mains
± 0.05%
Speed of frequency variation 1Hz/s
Overload with reference to the rated power: 110% for 60’, 125% for 10’ , 150% for 1’
Short circuit current 300% for 1 second with current limiting
Electrical Data 10 15 20 30 40 60 80 100
BY-PASS
Rated voltage 230Vca 1 phase + N (configurable from 220V to
240V)
Rated voltage tolerance ± 15% (adjustable from ± 10% to ± 25% from
control panel)
Rated current (230 V) [A] 43 65 87 130 174 260 348 435
Rated frequency [Hz] 50 or 60 (auto-sensing)
Frequency tolerance ± 2% ( ± 1% ÷ ± 6% from control panel)
Switching onto by-pass with synchronized Inverter
(UPS in “Normal Mode”)
Approx 0ms
Switching onto by-pass with Inverter out of sync
(UPS in “Normal Mode”)
~ 100 ms
Switching from by-pass to Inverter (UPS in “Stand-by On
mode”)
from 2 to 5ms
Delay in transfer onto Inverter after switching onto by-pass 4 s
Power overload capacity of the by-pass line (refer to rated
power):
110 % for 60 minutes, 125 % for 10 minutes, 150 %
for 1 minute
i²t SCR bypass (25°C, 8÷10ms) [A²s]
11 20 405 1805
Short circuit capacity of the by-pass line (x rated current):
1 s 4,7 5 3,8 5,7 5,4 4,2 3,7 7
500ms
4,9 5,3 4 6 5,7 5 4 8
200ms
5,3 5,7 4,3 6,7 6,3 5,3 4,5 9
100ms
5,8 6 4,6 6,9 6,6 5,7 5,1 10
10ms
6,2 7,5 6 8,4 8,6 7,8 7,7 14
