Pag. 54 / 57 0MNMPMK10NPENUB 00
6. General characteristics
Mechanical Data 10 15 20 30 40 60 80 100
Width [mm] 555 800
Depth/height [mm] 740 / 1400 800/
1900
Ventilation Forced
Max current dispersion [mA] 300 500
Noise at 1m from front (0÷100% load) [dBA] 60÷62
Applicable Standards Refer to the “Safety and Compliance Manual ”
supplied with the UPS (0MNA141_NE).
Electrical Data 10 15 20 30 40 60 80 100
RECTIFIER INPUT
Rated voltage 400Vac 3-phase
Rated voltage tolerance -25%, +20% ( 100% load)
- Battery in charge -10%, +20% ( 100% load)
- without battery contribution -18%, +20% ( 100% load)
Rated frequency [Hz] 50 / 60
Input frequency tolerance [Hz] from 45 to 65
Rated current absorbed (400 V) [A]
15 24 31 46 62 93 124 154
Rated power absorbed (400 V) [kVA]
11 16 22 32 43 64 86 106
Max current absorbed at full load and with battery recharging
[A]
22 33 44 66 87 131 175 218
Monoblocks/ Number of Pb elements 32 / 192 33/
198
Ripple voltage with recharged battery [%] Approx 0
Max recharge current [A]
Full load 2 2 4 6 8 12 16 20
Load 90% 5 5 9 13 18 26 36 44
Load 80% 7 7 14 21 27 41 56 69
Load ≤ 50% 15 15 18 37 37 75 75
110
Progressive start of rectifier (power walk-in 0-100%)
Configurable (0÷120s)
Delay of progressive start of rectifier (Power Walk-in delay
timer)
Configurable (0÷120s)
Current distortion, power factor (*):
LIBRAPRO version
27 %, ≥ 0,9 26 %, ≥ 0,9
LIBRAPRO + Filter
6 %, ≥ 0,9 5 %, ≥ 0,9
(*) load 100%, rated input voltage, and full charge battery.
