Elektropneumatic positioner DigiPos
7. Technical Data
24
7. Technical Data
7 . 1 Mechanical Data
Tab. 7 Mechanical Data
7 . 2 Pneumatic Data
Tab. 8 Pneumatic Data
External dimensions
(diameter x height)
Ø102 x 143mm
Housing material PA 6
Protective hood material Stainless steel 1.4301
Weight 1600 g
Protection class IP 65
Ambient temperature Min. 0° C - Max. 70° C
Installation position Vertical
Supply air pressure 6 bar recommended.
At low pressure this must be above the maximum
actuating pressure (necessary actuator pressure).
Air quality Compressed air filtered 5 µm, dry and oil-free.
If the compressed air is oiled, the quality must comply
with ISO VG32 class 1.
Litre capacity supply air valve
(unrestricted)
98 Liter / min
Litre capacity vent air valve (unre-
stricted)
98 Liter / min
Supply air connection Quick-fit air screw connection ¼“:
Suitable for plastic air hoses,
- inside Ø 4mm
- outside Ø 6mm
