Elektropneumatic positioner DigiPos
3. General information on the positioner
5
3. General information on the positioner
The DigiPos is an electronic positioner for pneumatically operated modulating valves. It is suitable
for membrane, piston and rotary actuators.
The DigiPos is adjusted in accordance with the respective valve during final assembly at the works
via an RS232 interface.
A commissioning software is used to this purpose for PCs with a serial interface.
This software can also be used when the system is taken into operation. During operation a
recorder function can be used to examine the behaviour of the control valve and optimise this
directly.
3 . 1 Basic functions
• Electronic positioner for pneumatic actuators
• 24 V DC, connection with 3 or 4 conductor technology
• Setpoint 4-20 mA
(can be set with setpoint potentiometer in manual operation)
• Position signalling 4-20 mA, 2-conductor technology (opto-decoupled)
• Position indication with LED display
• 2 external LEDs for indication of the end positions
• Automatic stroke alignment
• Variable control accuracy
• RS232 interface
3 . 2 Extended settings via the RS232 interface
• Recorder function for set and actual position value
only authorized people:
• Loading of firmware into the positioner, no exchange of the program memory necessary
• Access to all setting parameters
• Valve stroke characteristic curve can be defined by the user
ATTENTION
• The software parameter settings on the DigiPos may only be made by trained personnel.
• Use of the software is not mandatory for commissioning.
