Elektropneumatic positioner DigiPos
7. Technical Data
25
7 . 3 Elektric Data
Input:
Tab. 9 Elektric Data
Output:
Path measurement:
Miscellaneous Data:
Tab. 10 Miscellaneous Data
Connection 3 oder 4- conductor connection possible
Voltage supply 24 V DC +/- 10%
Current consumption 70 mA min. 40 / max. 110
Max. power consumption 2,7 W
Setpoint 4-20 mA
Setpoint input, resistance (load) 220 Ohm
Max. wire size 0,5mm²
Position indication output, range 4-20 mA
Inductive circular sensor 0-10 V
Service life 10 years
Control accuracy, variable 0,4-2,9 % (1% default setting)
Adjustment time 0,5 – 4 sek.
Solenoid valves, switching time 10 ms
Solenoid valves, current 20 mA max. 100 mA
Solenoid valves, service life 10 million cycles
