GSP-9300 Introduction
The GSP-9300 builds on the strong feature set of the GSP-930 and
significantly increases performance in almost every aspect; making
this the most comprehensive and feature-rich spectrum analyzer
GW Instek has released.
Like the GSP-930, the GSP-9300 features a split window display to
view data in spectrum, topographic or spectrographic views. There
are also a number of additional test functions such as 2FSK, 1PdB
and new dedicated EMC pretest functions for EMI and EMS testing.
Lastly, the GSP-9300 significantly reduces the sweep time and RBW
filter step resolution and complexity.
Main Features
Performance
 9kHz~3GHz bandwidth
 1Hz resolution
 Nominal RBW accuracy of ±5% <1MHz,
±8% =1MHz
 Video bandwidth 1Hz~1MHz (1-3-10 steps)
 Amplitude measurement range: DANL~30dBm
(frequency dependent)
 Input attenuation: 0 ~ 50dB, 1dB steps
 Phase noise: < -88dBc/Hz@1GHz, 10kHz,
typical
Features
 1-3-10 step increments for RBW bandwidth
 Three display modes: Spectrum, Topographic
and Spectrographic
 Split window display
 Built-in EMI filter
 Auto Wake-up
 Built-in preamplifier
