BASIC OPERATION
The Basic Operation chapter in this Quick Start Guide only covers a
few basic operations: how to view a signal, how to use a marker to
make a measurement and how to setup the LXI interface. For
comprehensive operating instructions, please see the user manual
on the accompanying User Manual CD.
Viewing a Signal
This section will give a brief overview on how
to view signals from the rear panel REF out
terminal. Only the basic settings will be shown.
. This will restore the factory default
settings. See the user manual for details.
2. Connect the REF out signal from the rear panel
to the RF Input on the front panel.
RF INPUT 50
W
+30dBm MAX.
MAX.DC ±50V
To Next Page
