When the power supply is set to operation mode,
the symbol of “＊” will be lighted up.
z When the Output is on, the symbol of “＊”
li
g
hts up to indicate the power suppl
y
is in
the operation mode, when the meter
displa
y
s the measurement value, the
symbol of “＊” becomes blinking.
10. CC
The CC light is on to indicate the instrument is
in the CC mode.
11. CV
The CV light is on to indicate the instrument is
in the CV mode.
12.
The light of “
” is on to indicate the
b
uzzer is
on.
13. Lock
The Lock light is on to indicate the
p
anel control
knobs is locked up.
PSM-SERIES PROGRAMMABLE POWER SUPPLY
USER MANUAL
 
13
Figure 4-1 Front Panel
