PSM-SERIES PROGRAMMABLE POWER SUPPLY
USER MANUAL
40
description.
RS232 cable configuration:
Figure 5-4 RS-232 Cable Configuration
Please enter to our web site for updated information:
http://www.goodwill.com.tw
PSM-SERIES PROGRAMMABLE POWER SUPPLY
USER MANUAL
41
5-4. The maximum value of the output setting
Model
PSM-2010 PSM-3004 PSM-6003
Output Range
Item
8V,20A 20V,10A 15V,7A 30V,4A 30V,6A 60V,3.3A
Output Voltage 8.240V 20.60V 15.450V 30.900V 30.900V 61.800V
Output Current 20.60A 10.30A 7.210A 4.120A 6.180A 3.400A
OVP (Over Voltage
Protection
22V 32V 64V
OCP (Over Current
Protection
22A 7.500A 6.500A
Step Voltage 8.000V 20.000V 15.000V 30.000V 30.000V 60.000V
Step Current 20.00A 10.00A 7.000A 4.000A 6.000A 3.300A
Delay Time 59’59.9”
Memory Group 100
