GW Instek PSM-2010 - MAINTENANCE; Fuse Replacement; Line Voltage Conversion; Measurement Techniques

PSM-SERIES PROGRAMMABLE POWER SUPPLY
USER MANUAL
 
v
6. MAINTENANCE.................................................................................43
6-1. FUSE REPLACEMENT .......................................................................43
6-2. LINE VOLTAGE CONVERSION ..........................................................43
6-3. MEASUREMENT TECHNIQUES..........................................................44
6-4. ADJUSTMENT AND CALIBRATION....................................................46
6-5. CLEANING........................................................................................51
7. THE SYSTEM DIAGRAM AND DESCRIPTION .........................52
7-1. BLOCK DIAGRAM ............................................................................52
7-2. THE CONFIGURATION OF BLOCK SYSTEM.......................................53
PSM-SERIES PROGRAMMABLE POWER SUPPLY
USER MANUAL
 
vi
SAFETY TERMS AND SYMBOLS
These terms may appear in this manual or on the product:
WARNING. Warning statements identify condition or
practices that could result in injury or loss of life.
CAUTION. Caution statements identify conditions or
practices that could result in damage to this product or
other property.
The following symbols may appear in this manual or on the product:
DANGER ATTENTION Protective Earth (ground) Frame or Chassis
High Voltage refer to Manual Conductor Terminal Terminal
Terminal
