PSM-SERIES PROGRAMMABLE POWER SUPPLY
USER MANUAL
4
Specification PSM-2010 PSM-3004 PSM-6003
Accuracy
Voltage 0.05% + 10mV
Programming
(@23℃±5℃)
,
±(% output
+ offset)
Current 0.2% + 10mA
Voltage 0.05% + 5mV
Readback
(@23℃ ±5 ℃ ),
±(% output
+ offset)
Current 0.15% + 5mA
Voltage
0.1% + 10mV
OVP/OCP
Accuracy,
±(% output
+ offset)
Current
0.4% + 10mA
Interface Command
proceeding time (The
average proceeding time
during receiving GPIB or
RS-232 command until
voltage output)
100ms
Load
Time
Full
Load
No
Load
Full
Load
No
Load
Full
Load
No
Load
Rise 95ms 45ms 50ms 20ms 80ms 100ms
Voltage Setting
Response Time
(Resistor Load)
Fall 30ms 450ms 45ms 400ms 30ms 450ms
Stability ±(% of output + offset): Following 1 hour warm-up, the output level drift
after 8 hours test under a fixed load, test lead and ambient temperature.
PSM-SERIES PROGRAMMABLE POWER SUPPLY
USER MANUAL
5
Specification PSM-2010 PSM-3004 PSM-6003
Voltage 0.02% + 1mV
Current 0.1% + 1mA
Memory Store/Recall points 0~99
Temperature Coefficient per ℃±(% of output + offset) : Maximum change in
output / readback per ℃ after 30-minute warm-up.
Voltage 0.01% + 3mV
Current 0.02% + 3mA
AC Input
100VAC, 120VAC, 220VAC ±10%,
230VAC, –6%+10%, 50/60Hz
Input Rating 700VA, 380W 300VA, 220W 600VA, 310W
Interface RS-232, GPIB
Accessories (1)
Power cord ×1, Instruction manual×1,
Programmer Manual×1
Type
Item
Common terminal
CE Safety
terminal
Test Lead 1 1 set
Sense Lead 0 1 set
Grounding Lead 0 1
Short bar A
on Front panel
3 0
Accessories (2)
Short bar B
on Rear panel
3 3
Operation
Environmental
Indoor use
Altitude up to 2000 m
Ambient temperature:
To satisfy specifications : 10℃~ 35℃( 50° F ~ 95°F )
Maximum operating ranges: 0℃~ 40℃( 32°F ~ 104°F )
Relative humidity: 85% RH (max.) non condensing
Pollution degree: 2
Storage Temperature &
Humidity
-10℃to 70℃, 70%RH (maximum)
Dimensions & Weight 230(W)×140(H)×380(L) mm. Approx. 10kg.
