H3C S1526 Installation Manual

Installation Manual
H3C S1526 Smart Ethernet Switch
Chapter 1 Product Overview
1-3
LED Status Description
Green A link is established.
OFF No link is established.
Link/Act
Blinking Data is being transmitted or received.
1.2.2 Rear Panel
The S1526 has one AC power socket on its rear panel, as
shown in
Figure 1-2.
Figure 1-2 Rear panel

H3C S1526 Specifications

General

Brand	H3C
Model	S1526
Category	Switch
Language	English
