Installation Manual
H3C S1526 Smart Ethernet Switch
Chapter 2 Installation
2-5
î Note:
The mounting brackets are used for fixing rather than weight bearing.
In a 19-inch standard rack, the weight of the switch is supported by
the tray beneath it.
2.2.2 Installing the Switch on a Workbench
In circumstances that a 19-inch standard rack is not available,
you can mount the switch on a clean workbench. You are
recommended to fasten the feet to the switch before installation.
Take the following steps to fasten the feet:
1) Remove the sticker on the feet accompanied with the
device.
2) Stick the feet to the round recesses on the bottom of the
device.
Figure 2-3 Fastening the feet to the switch
