H3C S1526 - Properties of Console Port

Installation Manual
H3C S1526 Smart Ethernet Switch
Chapter 5 Appendix – Port Properties
5-3
Item Description
Standard supported IEEE802.3ab
Media and
transmission
distance
50/125µm multimode optical fiber,
transmission distance up to 550 meters
(1,804 feet)
9/125µm single-mode short-reach optical
fiber, transmission distance up to 10 km
(6.2 miles)
9/125µm single-mode intermediate-reach
optical fiber, transmission distance up to 40
km (24.9 miles)
9/125µm single-mode long-reach optical
fiber, transmission distance up to 70 km
(43.5 miles)
5.4 Properties of Console Port
Table 5-4 Properties of Console port
Item Description
Connector type RJ-45
Port quantity One
Port standard Asynchronous EIA/TIA-232
Baud rate 9600 bps (default)
Media and
transmission
distance
Console cable, transmission distance up to
2 meters (6.6 in.)
