H3C S1526 Installation Manual

Installation Manual
H3C S1526 Smart Ethernet Switch
Chapter 5 Appendix – Port Properties
5-2
5.2 Properties of 1000 Mbps Ethernet Ports
Table 5-2 Properties of 1000 Mbps Ethernet ports
Item Description
Connector type RJ-45
Port quantity Two
Operating rate 10/100/1000 Mbps and Auto negotiation
Duplex mode
Half duplex, full duplex and auto
negotiation (10/100 Mbps)
Full duplex and auto negotiation (1000
Mbps)
Network cable
connection
MDI/MDI-X
Standards supported IEEE802.3, IEEE802.3u and IEEE802.3z
Media and
transmission
distance
CAT-5 twisted pair cable, transmission
distance up to 100 meters (328 feet)
5.3 Properties of SFP Module Ports
Table 5-3 Properties of SFP module ports
Item Description
Connector type LC
Port quantity Two
Operating rate 1000 Mbps
Duplex mode Full duplex
