Configuring an HBA-LSI-9300-8i-A1-X
storage controller
About the HBA-LSI-9300-8i-A1-X storage
controller
The HBA-LSI-9300-8i-A1-X storage controller supports 12-Gbps data channels. For storage
controller details, contact Technical Support.
RAID levels
The storage controller does not support configuring RAID arrays.
Configuring controller settings in UEFI mode
This section describes how to configure the storage controller settings in UEFI mode. For more
information about how to enter the BIOS and set the boot mode to UEFI, see the BIOS user guide
for the server.
Controller configuration tasks at a glance
To configure the storage controller settings in UEFI mode, perform the following tasks:
Accessing the controller configuration screen
(Optional.) View basic controller properties
(Optional.) Changing controller properties
(Optional.) Viewing drive properties
(Optional.) Locating drives
Accessing the controller configuration screen
1. Access the BIOS. Press Delete, Esc, or F2 as prompted during server POST to open the
BIOS setup screen as shown in Figure 1. For some servers, the Front Page screen opens,
and you must select Device Management before proceeding to the next step.
For how to navigate screens and modify settings, see the operation instructions at the lower
right corner.
