145
Figure 151 Summary information
Table 63 Field description
Field Descri
tion
Session Number
PPPoE session ID.
Dialer Interface Number
Number of the dialer interface corresponding to the PPPoE session.
Interface
Ethernet interface where the PPPoE session belongs. This field is null when the
PPPoE session is bundled with a VLAN interface.
Client-MAC
MAC address of the PPPoE client.
Server-MAC MAC address of the PPPoE server.
Status
PPPoE session state:
• IDLE: PPPoE client negotiation is not performed.
• PADI: PADI packets have been sent. The interface is waiting for the PADO
response.
• PADR: PADR packets have been sent. The interface is waiting for the PADS
response.
• PPPNEG: PPP negotiation is started.
• PPPUP: PPP negotiation is completed.
PPPoE client configuration example
Network requirements
Configure PPPoE client on the AP and enable the PPPoE client to communicate with the PPPoE server, as
shown in Figure 152.
Figure 152 Network diagram
