Haas Automatic Pallet Changer - APC PALLET CLEARANCES

96-0012 rev G
3
June 2003
OM PERATOR’S ANUAL
Automatic
Autom a t i c
Automatic
Autom a t i c
Pallet Changer
Pallet Changer
INTRODUCTION
APC PALLET CLEARANCES
A 1-1/4” D 3*
B 1-3/8”* E 1-1/2”*
C 6-1/4” F 4-1/2”*
*The same for both VF-3 and VF-4
