Section 6 Operation
6.1 Configure the instrument settings
1. Push , then push Setup.
2. Select an option.
Option Description
Location Sets the location name of the instrument. The location is sent with
measurements to the USB drive. The location is not saved to the data log.
Date & Time Sets the date format, the time format and the date and time. Enter the
current date and time. Date Format—Sets the date format. Options: dd-mm-
yyyy (default), yyyy-mm-dd, dd-mm-yyyy or mm-dd-yyyy. Time Format—
Sets the time format. Options: 12 or 24 hours (default).
Security Enables or disables password protection for the settings and tasks in the
security list. Security Password—Sets or changes the security
(administrator) password (10 characters maximum). Passwords are case
sensitive. Security List—Sets the security level for each setting and task in
the security list.
• Off—All operators can change the setting or do the task.
• One key—Only operators with a one-key or two-key security level can
change the setting or do the task. Refer to Add operator IDs on page 12.
• Two keys—Only operators with a two-key security level can change the
setting or do the task.
Note: The Security setting is not set to on until Close is pushed.
Sound Settings Enables or disables the sound settings for individual events. To enable or
disable all of the sound settings, select All and then push Setup.
Peripherals Shows the connection status of attached devices such as a Seiko DPU-
S445 printer, USB memory (flash drive) or keyboard.
Power
Management
Sets when the instrument is automatically set to sleep mode or off after a
period of no activity. Sleep Timer—Sets when the instrument is set to sleep
mode. Options: OFF, 30 minutes, 1 (default), 2 or 12 hours.
English 11
