Hach TU5300sc User Manual

Table 3-6. Alarm Function Codes - Word 1
(Read/Write at Address Base+137)
NAME BITS FUNCTION DESCRIPTION
Alarm 1 Enable, Sensor 1 0 1-Enable, 0-Disable
Alarm 1 Enable, Sensor 2 1 1-Enable, 0-Disable
Alarm 1 Enable, Sensor 3 2 1-Enable, 0-Disable
Alarm 2 Enable, Sensor 1 3 1-Enable, 0-Disable
Alarm 2 Enable, Sensor 2 4 1-Enable, 0-Disable
Alarm 2 Enable, Sensor 3 5 1-Enable, 0-Disable
Alarm 3 Enable, Sensor 1 6 1-Enable, 0-Disable
Alarm 3 Enable, Sensor 2 7 1-Enable, 0-Disable
Alarm 3 Enable, Sensor 3 8 1-Enable, 0-Disable
Alarm 1 Direction, Sensor 1 9 1-Increasing, 0-Decreasing
Alarm 1 Direction, Sensor 2 10 1-Increasing, 0-Decreasing
Alarm 1 Direction, Sensor 3 11 1-Increasing, 0-Decreasing
Alarm 2 Direction, Sensor 1 12 1-Increasing, 0-Decreasing
Alarm 2 Direction, Sensor 2 13 1-Increasing, 0-Decreasing
Alarm 2 Direction, Sensor 3 14 1-Increasing, 0-Decreasing
Not used 15
Table 3-7. Alarm Function Codes - Word 2
(Read/Write at Address Base+138)
NAME BITS FUNCTION DESCRIPTION
Alarm 3 Direction, Sensor 1 0 1-Increasing, 0-Decreasing
Alarm 3 Direction, Sensor 2 1 1-Increasing, 0-Decreasing
Alarm 3 Direction, Sensor 3 2 1-Increasing, 0-Decreasing
Alarm 1 Latch Status, Sensor 1 3 0 - Non-Latching, 1 - Latching
Alarm 1 Latch Status, Sensor 2 4 0 - Non-Latching, 1 - Latching
Alarm 1 Latch Status, Sensor 3 5 0 - Non-Latching, 1 - Latching
Alarm 2 Latch Status, Sensor 1 6 0 - Non-Latching, 1 - Latching
Alarm 2 Latch Status, Sensor 2 7 0 - Non-Latching, 1 - Latching
Alarm 2 Latch Status, Sensor 3 8 0 - Non-Latching, 1 - Latching
Alarm 3 Latch Status, Sensor 1 9 0 - Non-Latching, 1 - Latching
Alarm 3 Latch Status, Sensor 2 10 0 - Non-Latching, 1 - Latching
Alarm 3 Latch Status, Sensor 3 11 0 - Non-Latching, 1 - Latching
Relay State-
without alarm condition 12 1 - Normally Energized,
0 - Normally De-Energized
Relay State-
without alarm condition 13 1 - Normally Energized,
0 - Normally De-Energized
Relay State-
without alarm condition 14 1 - Normally Energized,
0 - Normally De-Energized
Not used 15
3-5
