Model 6 Motor Control Centers 80459-641-01E
Section 12—Insulation Resistance 10/2012
© 1999–2012 Schneider Electric All Rights Reserved110
ENGLISH
Ambient-Compensated Bimetallic Overload Selection Tables for Part Winding Combination Starter Units
Size 1 Size 2
Motor
Full-Load
Current (A)
Thermal Unit
Number
Motor
Full-Load
Current (A)
Thermal Unit
Number
Motor
Full-Load
Current (A)
Thermal Unit
Number
Motor
Full-Load
Current (A)
Thermal Unit
Number
1.14–1.21 AR 1.05 6.92–7.63 AR 5.8 8.48–9.25 AR 8.5 33.0–37.9 AR 35
1.22–1.33 AR 1.15 7.64–8.41 AR 6.4 9.26–10.11 AR 9.3 38.0–43.3 AR 40
1.34–1.47 AR 1.26 8.42–9.31 AR 7.0 10.12–11.09 AR 10.2 43.4–46.7 AR 44
1.48–1.63 AR 1.39 9.32–10.59 AR 7.7 11.10–12.27 AR 11.2 46.8–49.9 AR 47
1.64–1.81 AR 1.53 10.60–11.69 AR 8.5 12.28–12.89 AR 12.4 50.0–53.9 AR 51
1.82–2.11 AR 1.68 11.70–12.55 AR 9.3 12.90–14.97 AR 13.6 54.0–58.3 AR 55
2.12–2.31 AR 1.85 12.56–13.95 AR 10.2 14.98–17.11 AR 15.4 58.4–62.7 AR 60
2.32–2.51 AR 2.04 13.96–15.19 AR 11.2 17.12–19.49 AR 17.6 62.8–67.1 AR 66
2.52–2.71 AR 2.24 15.20–15.79 AR 12.4 19.50–22.3 AR 20.5 67.2–73.8 AR 72
2.72–2.95 AR 2.46 15.80–17.91 AR 13.6 22.4–25.5 AR 23 74.0–78.3 AR 79
2.96–3.17 AR 2.71 17.92–20.7 AR 15.4 25.6–28.9 AR 27 78.4–81.9 AR 86
3.18–3.49 AR 2.98 20.8–23.5 AR 17.6 29.0–32.9 AR 30 82.0–90.0 AR 94
3.50–3.89 AR 3.28 23.6–26.7 AR 20.5
3.90–4.41 AR 3.62 26.8–30.5 AR 23
4.42–4.95 AR 3.98 30.6–34.5 AR 27
4.96–5.53 AR 4.37 34.6–39.5 AR 30
5.54–6.15 AR 4.80 39.6–44.9 AR 35
6.16–6.91 AR 5.30 45.0–52.0 AR 40
Size 3 Size 4
Motor
Full-Load
Current (A)
Thermal Unit
Number
Motor
Full-Load
Current (A)
Thermal Unit
Number
Motor
Full-Load
Current (A)
Thermal Unit
Number
Motor
Full-Load
Current (A)
Thermal Unit
Number
54.2–60.1 E 67 94.0–103.1 E 74 100–111.9 E 88 164–173.9 E 96
60.2–66.5 E 69 103.2–114.1 E 76 112–121.9 E 89 174–185.9 E 97
66.6–71.5 E 70 114.2–125.7 E 77 122–131.9 E 91 186–195.9 E 98
71.6–78.9 E 71 125.8–138.3 E 78 132–139.9 E 92 196–215.9 E 99
79.0–86.9 E 72 138.4–150.1 E 79 140–151.9 E 93 216–227.9 E 101
87.0–93.9 E 73 150.2–166.6 E 80 152–163.9 E 94 228–251.9 E 102
Size 5
Motor
Full-Load
Current (A)
Thermal Unit
Number
Motor
Full-Load
Current (A)
Thermal Unit
Number
210–233 AR 3.28 332–369 AR 4.8
234–265 AR 3.62 370–415 AR 5.3
266–297 AR 3.98 416–459 AR 5.8
298–331 AR 4.37 460–532 AR 6.4
