ONYX Electrostatic Discharge Simulator
23
7 Accessories and Options
7.1 ONYX Accessories
The following accessories are included with the basic version of
ONYX ESD simulator:
• Carrying case
• Quick start guide
• User manual
• Air discharge tip
• Contact discharge tip
• RC module IEC / ISO 150pF/330 Ohm
• Two rechargeable battery packs
• Battery charger including AC adapter for
Europe, USA, China, UK
• Earth cable
• Factory calibration certificate
Following additional accessories or spare material can be ordered separately:
Article Article Number
RC Modules:
150pF / 2000 Ohm 2490204
330pF / 2000 Ohm 2490205
330pF / 330 Ohm 2490206
100pF / 1500 Ohm 2490207
150pF / 150 Ohm 2490208
500pF / 500 Ohm 2490209
500pF / 5000 Ohm 2490210
xxxxpF / xxxx Ohm (custom) 2490211
Air discharge tip 30kV / 30mm 2490212
Fast rise time tip 0.3ns 2490213
AC mains adapter 2490214
Remote control package (see Fig. 16 below) 2490216
Accredited calibration 2499981
ESD Verification set IEC/EN 61000-4-2 edition 2 2499971
Vertical Coupling Plane with resistor cable 2495581
Horizontal Coupling Plane with resistor cable 2496881
ESD wooden test table 2496871
Resistor cable 2x470 kOhm 2498101
