ONYX Electrostatic Discharge Simulator

3.2 Operating Conditions

Operating Temperature Range +15…+35°C

Storage Temperature Range -10…+50°C

Air humidity 20...80 % r.h, non condensing

Air pressure 86...106 kPa

3.3 Mechanical Data

Dimensions: approx. W 290mm x H 270mm x D 110mm

Weight: approx. 1.7kg

Tripod screw thread ¼ inch UNC (standard camera tripod screw thread)

3.4 Standards

Standards covered by ONYX

• IEC/EN 61000-4-2 edition 1 + 2 (default)

• ISO 10605

• IEC/EN 61326

• IEC/EN 61000-6-1 & -6-2

• IEC 61340-3-1

• GMW 3097

• Ford AB/AC

• ANSI C63.16

• PSA B21 7110

• ISO 14304

• ITU-T K.20

• MIL-STD-331/-464/-750/-883/-1512/-1514/-1541/-1542

• RTCA/DO-160

• JEDEC 22-A114

• GR-78-CORE

• GR-1089-CORE

and others

3.5 General

The equipment must not be

subjected to:

• direct solar radiation

• water ingress

• dirty or dusty atmospheres

• excessive vibration

• electromagnetic interference
